VentryWall Mounts - Large / X-Large Flat Screen
Wall Mounts
*35kg (77lbs) when pole mounted
 Designed for large flat screens up to 55”(140cm) / 25kg (55lbs)
 Fits screens with VESA® and non-VESA® mounting patterns
up to 600 x 400mm
 Features +/-10° tilt and 180° swivel
 Distance from wall:
Min: 35mm (1.4”)
Max: 535mm (21.1”)
 Integrated Spirit Level and cable management
Ultra-Slim Double Arm Flat Screen
Wall Mount with Tilt and Swivel
Double Arm - Large BTV514
10˚ VESA
600
x
400 55"140cm 10˚
180˚
25kg
RegisteredDesignNumber: 001334981-0007
BTV510
 Designed for large flat screens
up to 55”(140cm) / 50kg (110lbs)
 Fits screens with
mounting patterns up to:
H: 425mm (16.7”) x V: 400mm (15.7”)
including screens using VESA®
fixings up to 400 x 400mm
 Low profile design mounts screen
only 20mm (0.8”) from wall
 Security locking bar to prevent
unauthorised screen removal
Universal Flat Screen
Wall Mount
Fixed - Large
RegisteredDesignNumber:001713280-0021
VESA
400 55"140cm
50kg
BTV520 Fixed - X-Large
 Designed for extra large flat screens
up to 65”(165cm) / 70kg (154lbs)
 Fits screens with
mounting patterns up to:
H: 825mm (32.5”) x V: 500mm (19.7”)
including screens using VESA®
fixings up to 800 x 500mm
 Low profile design mounts screen
only 20mm (0.8”) from wall
 Security locking bar to prevent
unauthorised screen removal
Universal Flat Screen
Wall Mount
RegisteredDesignNumber:001713280-0011
65"165cm
VESA
800
x
500
70kg
BTV511
Universal Flat Screen
Wall Mount with Tilt
 Designed for large flat screens
up to 55”(140cm) / 50kg (110lbs)
 Fits screens with mounting
patterns up to:
H: 430mm (16.9”) x V: 400mm (15.7”)
including screens using VESA®
fixings up to 400 x 400mm
 5 fixed tilt positions up to +15°
 Mounts screen only
44mm (1.7”) from wall
 Security locking bar to prevent
unauthorised screen removal
Tilt - Large
RegisteredDesignNumber: 001713280-0023
VESA
400
55"140cm 15˚
50kg
BTV521 Tilt - X-Large
 Designed for extra large flat screens
up to 65”(165cm) / 70kg (154lbs)
 Fits screens with
mounting patterns up to:
H: 825mm (32.5”) x V: 500mm (19.7”)
including screens using VESA®
fixings up to 800 x 500mm
 5 fixed tilt positions up to +15°
 Mounts screen only
44mm (1.7”) from wall
 Security locking bar to prevent
unauthorised screen removal
Universal Flat Screen
Wall Mount with Tilt
RegisteredDesignNumber:001713280-0024
VESA
800
x
500
65"165cm 15˚
70kg
10˚
