VideoWall Mount Adaptors & Spacers
If you have a bespoke spacer requirement we are also able tomake these to order with noM.O.Q.
Mounting with Spacers - Landscape
Wallplatespacersareavailable forthe BT8310 andBT8311 thateliminatetediousalignment
calculations, meaning less time is wasted throughmeasuring and‘guesswork’.These spacers
are available to order separately and are screen specific for all popular brands. To find out
which spacer kit is needed for a specific screen please see the table below.
If your screen is not listed in
the table below please go to
or scan the QR code above to view the
most up to date list. Mounting with Spacers - Portrait
Spacer Kits
 Eliminate tedious alignment calculations and guess work
 Spacers available for all video wall screen brands
such as LG, Samsung, Sharp, Philips, NEC, and Orion
 Only one spacer kit is required per install and can be re-used for multiple installations
 See table below to find out which spacer is required for your installation
CustomWall Plate Spacers for BT8310
and BT8311 VideoWall Mounts
BT8310-SP
Screen Brand Model Screen Size Spacer Available VESA Adaptor Required*
Samsung UD46D 46”(1022 x 577mm) BT8310-SP461/N BT7564
NEC X464UNS 46”(1022 x 576mm) BT8310-SP461/N Not Required
Philips BDL4678XL 46”(1023 X 578mm) BT8310-SP461/N Not Required
NEC X464UNV 46”(1024 x 579mm) BT8310-SP461/N Not Required
NEC X464UN-2 46”(1024 x 579mm) BT8310-SP461/N Not Required
NEC X464UNV-2 46”(1024 x 579mm) BT8310-SP461/N Not Required
Philips BDL4677 46”(1024 x 579mm) BT8310-SP461/N Not Required
Samsung UE46D 46”(1031 X 585mm) BT8310-SP462/N Not Required
Philips BDL4777XL 47”(1045 x 590mm) BT8310-SP471/N Not Required
Panasonic TH-47LFV 47”(1047 x 592mm) BT8310-SP551/N Not Required
LG 47WV50 47”(1047 x 592mm) BT8310-SP471/N BT7564
LG 47LV35A-5B 47”(1047 x 592mm) BT8310-SP471/N BT7564
Panasonic TH-55LFV-70 55”(1213 x 684mm) BT8310-SP551/N Not Required
Philips BDL5588XL 55”(1213 x 684mm) BT8310-SP551/N Not Required
LG 55LV35A-5B 55”(1215 x 686mm) BT8310-SP551/N BT7564
LG 55LV75A 55”(1215 x 686mm) BT8310-SP551/N BT7564
LG 55LV77A 55”(1215 x 686mm) BT8310-SP551/N BT7564
NEC X554UN 55”(1215 x 686mm) BT8310-SP551/N Not Required
NEC X554UN-2 55”(1215 x 686mm) BT8310-SP551/N Not Required
NEC X554UNV 55”(1215 x 686mm) BT8310-SP551/N Not Required
Panasonic TH-55LFV 55”(1215 x 686mm) BT8310-SP551/N Not Required
Samsung UD55D 55”(1215 x 686mm) BT8310-SP551/N BT7564
Samsung UE55D 55”(1222 x 693mm) BT8310-SP552/N Not Required
Samsung PN-V602 60”(1336 x 755mm) BT8310-SP601/N Not Required
This listreflectsthe latestvideowallscreensavailableonthemarket (atthetimeofprinting), foracomplete list, includingoldermodels,pleasesee
Accessories - VESAAdaptors and Spacers for BT8310 and BT8311
*VESA adaptors now
included as standard!
