2016 B-Tech Catalogue

63 / 100

Projector
Mounts
For More Information Visit B-TECH PROFESSIONAL 63
BT884 Short Throw
Short ThrowProjectorWall Mount
with Adjustable Arm
 Designed for Short Throw Projectors
up to 10kg
 Features +/-20° tilt and +/-20° roll
 Telescopic design for correct
projector positioning
 Cable management included
 Coverplate included for smart installation
 Maximum distance between
any two fixing points: 300mm
Available in 2 lengths
BT884-M
 Telescopic arm mounts projector
400mm - 575mm fromwall
BT884-L
 Telescopic arm mounts projector
880mm - 1510mm fromwall
 Designed for projectors
up to 10kg
 Features +/-90° tilt, +/-90° roll
and 360° swivel
 Suitable for angled / cathedral ceilings
 Maximum distance between any two
fixing points on projector: 340mm
 Hand lever for easy adjustment
of ceiling drop:
Min: 580mm
Max: 830mm
Projector CeilingMount
with Adjustable Drop
BT882 Medium Adjustable Drop
RegisteredDesignNumber:3016251
10kg
BT881
 Designed for projectors
up to 10kg
 Mounts projector only 115mm
from ceiling or 280mm with
supplied extension rod
 Features +/-90° tilt adjustment, +/-90°
roll adjustment and 360° swivel
 Maximum distance between any two
fixing points on projector: 340mm
Projector
Ceiling Mount
Short Drop BT899 Heavy Duty
Projector Ceiling Mount
with Micro-Adjustment
 Designed for projectors
up to 25kg
 Compatible with the B-Tech System
2™ Professional Range and NPT pipe
systems (see page 68 for more info)
 Features +/-13° tilt, +/-6° roll
and 360° swivel
 Maximum distance between any
two fixing points: 370mm
10kg
RegisteredDesignNumber:001713306-0004
13˚
13˚ 360° 6˚
6˚
25kg
Adjustable Projector Mounts
BT899-XL Extra Large Projector Ceiling
Mount withMicro-Adjustment
 Maximum distance between any two fixing points: 493mm
 Compatible with System 2 - see page 68 for more info
 Designed for projectors
up to 10kg
 Features +/-90° tilt, +/-90° roll
and 360° swivel
 Suitable for angled / cathedral ceilings
 Maximum distance between any two
fixing points on projector: 340mm
 Hand lever for easy adjustment
of ceiling drop:
Min: 830mm
Max: 1330mm
Projector CeilingMount
with Adjustable Drop
Long Adjustable Drop
RegisteredDesignNumber:3016251
10kg
20˚
20˚
10kg
20˚
20˚
BT883
