50mmPole
Mounting System
For More Information Visit B-TECH PROFESSIONAL 77
Specialist PoleMounts & Accessories
BT7012 Purlin Mount
Purlin Mount
for ø50mm Poles
 Adjustable purlin mount for use with
50mm poles
 Cable management
 Supplied with safety bolt for secure installation
 Locking bolt included to securely set the pole
vertical at any angle up to 45°
 Fits“Cee”and“Zee”section purlin
with a minimum height of 95mm
 Can also be mounted to beams and girders
 Pole sold separately 140kg
BT7014 Joist Mount
 Designed to be mounted to the
side / underside of a beam / joist
 Supplied with safety bolt for
secure installation
 Can be bolted through a joist
using supplied back plates
 Screws / bolts not included
 Pole sold separately
BT7014
BT7850
Joist Mount
for ø50mm Poles
100kg
BT7825 Truss Clamp
 Adjustable adaptor for attaching
50mm poles to truss systems,
scaffolding and other horizontal poles
 Cable management
 Supplied with safety bolt for
secure installation
 Fits truss size from 42mm - 50mm
 Zinc plated clamp
 Pole sold separately
Truss Mount
for ø50mm Poles
140kg
BT7017 I-Beam (Girder) Mount
 Adjustable I-Beam (girder) mount
for use with 50mm poles
 Cable management
 Supplied with safety bolt for secure
installation
 Locking bolt included to securely set
the pole vertical at any angle up to 36°
 Fits I-Beams and thick steel from
80mm - 250mm in width
 Pole sold separately
I-Beam Girder Mount
for ø50mm Poles
36˚
36˚
140kg
BT7055 Pole Finishing Ring
 Escutcheon ring designed to
improve the look of a ceiling
mounted pole
 Can be retro-fitted onto poles, using
new split design for easier installation
 Ideal for use with
suspended ceilings
 Pole sold separately
Ceiling Finishing Ring
for ø50mm Poles
BT7056 Floor Fixing Kit
 Allows poles to be fixed to the
floor to prevent lateral movement
in a floor to ceiling installation
 Cover can be retro-fitted onto poles,
using new split design
 Suitable for most floor types
including concrete and
wooden floors
 Black or Chrome cover for a smart installation
Floor Fixing Kit for
50mm Poles
Pole Joiners
 Allows a rigid join of 2x ø50mm poles
 Heavy duty steel supports substantial
loads with minimal movement
 Allows cables to pass through the
poles and joiner
 Allows cable access mid-pole
 Supplied with safety bolts for secure install
 Includes grub screws which allow
micro-adjustment of pole angle
 Poles sold separately
Internal Pole Joiner
for ø50mm Poles
External Pole Joiner
ø50mm Poles
BT7823 BT7824
Updated
Product
Updated
Product
RegisteredDesignNumber:002741256-0005
Pole Joiners
Updated
Product
 Allows a rigid join of 2x ø50mm poles
 Heavy duty steel supports substantial
loads with minimal movement
 Hidden from view once installed for a
seamless pole join
 Allows cables to pass through the
poles and joiner
 One-piece design for a quick install
 Poles sold separately
