2016 B-Tech Catalogue

85 / 100

For More Information Visit B-TECH CONSUMER 85
Flat Screen
Wall Mounts VentryWall Mounts - Small
 Designed for screens up to 23”(58cm) / 20kg
 Fits screens with VESA® mounting patterns: 75 x 75 and 100 x 100mm
 Low profile design mounts screen only 15mm from wall
Ultra-Slim Flat ScreenWall Mount
BTV110
BTV112 Tilt and Swivel - Small
 Designed for screens up to 23”(58cm) / 15kg
 Fits screens with VESA®mounting patterns: 75 x 75 and 100 x 100mm
 Features +/-15° tilt and 180° swivel
 360° screen rotation
 Distance from wall: 105mm
 Integrated Spirit Level and cable management
 Interface can be secured in place with a padlock (not supplied)
Flat ScreenWall Mount with Tilt and Swivel
RegisteredDesignNumber: 001334981-0001
Double Arm Flat ScreenWall Mount
with Tilt and Swivel
 Designed for screens up to 23”(58cm) / 15kg
 Fits screens with VESA® mounting patterns: 75 x 75 and 100 x 100mm
 Features +/-15° tilt and 180° swivel
 360° screen rotation
 Distance from wall: Min: 105mm Max: 385mm
 Integrated Spirit Level and cable management
 Interface can be secured in place with a padlock (not supplied)
RegisteredDesignNumber: 001334981-0006
BTV113 Fixed - Small Single Arm - Small
 Designed for screens up to 23”(58cm) / 15kg
 Fits screens with VESA® mounting patterns:
75 x 75 and 100 x 100mm
 Features +/-15° tilt and 180° swivel
 360° screen rotation
 Distance from wall: Min: 105mm Max: 240mm
 Integrated Spirit Level and cable management
 Interface can be secured in place with a padlock (not supplied)
Single Arm Flat ScreenWall Mount
with Tilt and Swivel
VESA
100 23"58cm
15˚
15˚ 180˚
15kg
RegisteredDesignNumber: 001334981-0002
BTV114 Double Arm - Small
VESA
100
15˚
15˚ 180˚
15kg 23"
58cm
RegisteredDesignNumber: 566831-0001
23"58cm
VESA100 20kg
VESA
100
15˚
15˚ 180˚
15kg 23"
58cm
