Mounting Plates & Screen Interfaces 50mmPole
MountingSystem
70kg
BT8026 Fixed Screen Mount
 2, 2-Piece split collars included
 Mounts screen in landscape or portrait style
 Security Allen key and screws provided
 Supplied with safety bolt for secure
installation
 Simple ‘hook-on’ installation with all
mounting hardware included
 Use with BT8009 for back-to-back screen
installations
 Can be used with both vertical and
horizontal poles
 Ceiling mounts, pole and flat screen
interface sold separately
 Must be used with flat screen interface kit
(BT7507 / BT8500)
Large Flat Screen 50mm Pole Mount
BT8026
BT7850
BT8009 Low Profile
Flat Screen Mounting Plate
 Suitable for concrete / brick or stud walls
up to 12”(30cm)
 Mounts screen only 22mm from wall when a
BT7507 interface kit is used and 41mm (1.6”)
when a BT8500 / BT8501 is used
 Compatible with BT8026, BT8027
for back-to-back screen mounting
 Fixes to non B-Tech trolley / floor stands (with
pole centres 62.5mm (2.5”) - 157.5mm (6.2”)
or 204mm (8”) - 299mm (11.8”) using
accessory collars
 Fits industry standard 150 x 150mm (5.9 x 5.9”)
fixing points
 Collars not included
 Mustbeusedwithflatscreeninterfacekit
(BT7507/BT8500/BT8501)
x2
70kg
BT7507 VESA® Screen
VESA® Interface Kit
 Suitable for screens
up to 70kg (154lbs)
 Fits 75 x 75, 100 x 100, 200 x 100 and
200 x 200mmVESA® mounting patterns
 Suitable for screens using
M4, M5, M6 and M8 fixings
 Can be fitted to mount in either
landscape or portrait style
 Must be used with a professional
screen mounting solution
(BT8009 / BT8026 / BT8027)
VESA200 70kg
BT8500 Large
Universal Interface Kit
 Suitable for screens
up to 70kg (154lbs)
 Maximum distance
between fixings:
H: 755mm (29.7”) x V: 410mm (16.1”)
 Fits all VESA® fixings
up to 600 x 400mm
 Can be fitted to mount in either
landscape or portrait style
 Must use with a professional
screenmounting solution
(BT8009/BT8026/BT8027/BT4002)
VESA
600
x
400
70kg
BT8027 Tilt Screen Mount
 2, 2-Piece split collars included
 Tilts up to +20˚ with fixed positions of
0˚, 15˚ and 20˚
 2 Heavy duty collars included with covers
 Mounts screen in landscape or portrait style
 Supplied with safety bolt for secure
installation
 Use with BT8009 for back-to-back screen
installations (only one screen will tilt)
 Can be used with both vertical and
horizontal poles
 Ceiling mounts, pole and flat screen
interface sold separately
 Must be used with flat screen interface kit
(BT7507 / BT8500)
BT8026
BT7850
20˚
70kg
40kg
BT7861 Adaptor Plate
 Designed to attach BT7532
(see page 6)to 150 x 150mm
interfaces
 Max load 40kg
 Compatible with ø50mm
and ø60mm collars
(available separately)
Adaptor Plate for
150 x 150mm fixings
x2
Large Flat Screen 50mm Pole Mount
with Tilt
