B-Tech 2015 Product Catalogue

34 / 72

For More Information Visit B-TECH PROFESSIONAL 34
Flat Screen CeilingMount
Tilt & Swivel BT7553
Tilt BT8424
 Flat screen ceiling mount designed for screens up to 55”(140cm) / 35kg (77lbs)
 Fits screens with mounting patterns up to H: 465mm (18.3”) x V: 400mm (15.7”) including
creens using VESA® fixings up to 400 x 400mm
 Features +/ -18° Tilt
 Unique ‘Torsion-Tilt’mechanism
 Ceiling drop: 1000mm (39")
 Security locking screw, Allen key and locking bars provided
 Integrated cable management
 Simple ‘hook-on’ installation
 Coverplate included
 Ceiling fixings and all mounting hardware included
Flat Screen CeilingMount withTilt
CeilingMounts - Fixed Drop Flat Screen
CeilingMounts
 Designed for screens using VESA® mounting patterns
75 x 75 or 100 x100mm up to 23kg (51lbs)
 Features +/ -10° Tilt
 360° swivel
 360° screen rotation
 Integrated cable management
 Coverplate included
 Ceiling fixings and all mounting hardware included
VESA
100
10˚
10˚ 360˚
23kg
Available in 5 lengths
1.5m Pole BT7553-150
2m Pole BT7553-200
50cm Pole BT7553-050
1m Pole BT7553-100
25cm Pole BT7553-025
55"140cm
VESA
400 18˚
18˚
35kg
*tocentreofmount
Ceiling drop: 1000mm BT8424
Available in 1 length
Back-to-Back
Mounts
Adjustable
Mounting
Support
Cable
Management
Fixed or
Adjustable
Tilt
Have you considered ceiling mounting your screen?
In many situations, ceiling mounting a screen is an attractive alternative to wall mounting. Ideal for open plan areas, ceiling mounting allows you to position
your screen in the perfect location in the room, without having to focus the rest of the room around a wall. With solutions for both flat and angled ceilings,
for either single or double screens B-Tech have mounting options for virtually any application.
Flat Screen Ceiling Features
NEW
