Flat Screen CeilingMount Back-to-Back
Small
 Designed for screens using VESA® mounting patterns
75 x 75 or 100 x100mm up to 23kg (51lbs) per screen
 Features +/ -10° Tilt
 360° swivel
 360° screen rotation
 Integrated cable management
 Coverplate included
 Ceiling fixings and all mounting hardware included
BT7554
Flat Screen CeilingMount withTilt
Medium / Large BT8428
Back-to-Back Flat Screen CeilingMount withTilt
X-Large BT8429
CeilingMounts - Fixed Drop Back-to-Back Flat Screen
CeilingMounts
Available in 5 lengths
1.5m Pole BT7554-150
2m Pole BT7554-200
50cm Pole BT7554-050
1m Pole BT7554-100
25cm Pole BT7554-025
 Designed for two medium/large flat screens up to 55”(140cm) / 35kg (77lbs) per screen
 Fits screens with mounting patterns up to H: 465mm (18.3”) x V: 400mm (15.7”)
including screens using VESA® fixings up to 400 x 400mm
 Simple tilt adjustment +/-18°
 Unique ‘Torsion-Tilt’mechanism
 Integrated cable management
 Pole can be tilted up to 70° for mounting on angled ceilings
 Supplied with safety bolt and locking bars for a secure installation
 Coverplate included for a smarter installation
 Designed for two extra large flat screens up to 65”(165cm) / 35kg (77lbs) per screen
 Fits screens with mounting patterns up to H: 825mm (32.5”) x V: 500mm (19.7”)
including screens using VESA® fixings up to 800 x 500mm
 Simple tilt adjustment +/-15°
 Unique ‘Torsion-Tilt’mechanism
 Integrated cable management
 Pole can be tilted up to 70° for mounting on angled ceilings
 Supplied with safety bolt and locking bars for a secure installation
 Coverplate included for a smarter installation
VESA
100
10˚
10˚ 360˚
23kg
*tocentreofmount
Ceiling drop*: 1452mm BT8428-150
Ceiling drop*: 1952mm BT8428-200
Ceiling drop*: 952mm BT8428-100
Available in 3 lengths
RegisteredDesignNumber:001713280-0035 PatentApplicationNumber:817023.5
*tocentreofmount
Ceiling drop*: 1452mm BT8429-150
Ceiling drop*: 1952mm BT8429-200
Ceiling drop*: 952mm BT8429-100
Available in 3 lengths
RegisteredDesignNumber:001713280-0036 PatentApplicationNumber:817023.5
65"165cm
VESA
800x
500 15˚
15˚
35kg
55"140cm
VESA
400 18˚
18˚
35kg
perscreen
perscreen
perscreen
