For More Information Visit B-TECH PROFESSIONAL 37
Medium / Large BT8426
Extra-Large BT8427
Extra-Large BT8447
CeilingMounts - Adjustable Drop Flat Screen
CeilingMounts
 Designed for extra large flat screens up to 65”(165cm) / 70kg (154lbs)
 Fits screens with mounting patterns up to H: 755mm (29.7”) x V: 410mm (16.1”)
including screens using VESA® fixings up to 600 x 400mm
 Adjustable ceiling drop: 658mm (25.9”) - 958mm (37.7”)
(from ceiling to centre of interface)
 Easy adjustment of tilt +20°
Adjustable Drop Universal Flat Screen
Ceiling Mount with Tilt
 Designed for medium / large flat screens up to 55”(140cm) / 40kg (88lbs)
 Fits screens with VESA® mounting patterns from 75 x 75 up to 400 x 400mm
 Adjustable Drop: 625mm (24.6”) - 850mm (33.5”) (from ceiling to centre of interface)
 Easy adjustment of tilt +15° with fixed positions of 0°, +7.5° and +15°
Adjustable Drop Flat Screen
Ceiling Mount with Tilt
RegisteredDesignNumber:4003130,4003650
55"140cm 15˚
VESA
400 40kg
RegisteredDesignNumber:4003130,4003650
VESA
600
x
400
65"165cm 20˚
70kg
 Flat screen ceiling mount designed for screens up to 65”(165cm) / 35kg (77lbs)
 Fits screens with mounting patterns up to H: 825mm (32.5”) x V: 500mm (15.7”)
including screens using VESA® fixings up to 800 x 500mm
 Adjustable Drop: 668mm (26.3”) - 943mm (37.1”)
 Features +/ -15° Tilt
 Unique ‘Torsion-Tilt’mechanism*
 Security locking screw, Allen key and locking bars provided
 Integrated cable management
 Simple ‘hook-on’ installation
 Coverplate included
 Ceiling fixings and all mounting hardware included
Flat Screen CeilingMount
with Adjustable Drop andTilt
VESA
800
x
500
65"165cm
35kg
15˚
15˚
NEW
